August 22, 2019

Modality Performed Procedure Step: reliable feedback from your diagnostic equipment

MPPS Image

Along with Modality Worklist, which enables your information system to send study inquiries to diagnostic equipment, you can use one more DICOM tool, Modality Performed Procedure Step (also known as MPPS). Conversely to Modality Worklist, it enables your machines to send feedback to your RIS, HIS, PACS or another system (for example, you may use an integrated IT solution which combines all these tools). Like many other DICOM tools, it is an optional feature, so you might need to pay extra for it. Today, we will talk about the features of Modality Performed Procedure Step, the basic principles of its function and the benefits it offers.

What is it for? When you order imaging studies, you might be concerned about the timeliness and quality of the scheduled examinations. Everything must go smoothly, without equipment failures or technologist mistakes.

If something has gone wrong, you will be probably notified that the study hasn’t been performed instead of receiving the images. Moreover, you will discover that at the last moment, when you expect the study to be completed. As a result, you become unable to make any adjustments to the schedule and lose revenues.

MPPS eliminates these issues; so, if you haven’t implemented it yet, your business may run into a bottleneck even at the initial workflow stages.

How it works. Having received an order from Modality Worklist, the diagnostic unit starts sending messages to the DICOM server connected to your information system. The system generates messages automatically (except for patient demographics, which is in most cases copied from the worklist). Particularly, these messages can tell you about:

  • The incoming order. Besides data retrieved from Modality Worklist, you will know the study accession number.
  • The actual performed study, which sometimes differs from what was scheduled initially. For instance, the technologist may have chosen a different protocol for the examination or decided to take an additional set of images.
  • Procedure status information. The diagnostic machine sends a status message to the server when the study is started, completed, paused or canceled (along with the cancellation reason). As for the cancellation reasons, DICOM has standardized many of them, so the fault management becomes much more efficient.
  • The technologist’s name, radiation dose, modality hardware condition, and even billing and insurance information.

Performance of this intelligent feature is based on the connection between your equipment and DICOM server; therefore, it requires proper configuration.

What benefits does it offer? You get several considerable advantages at the study performance stage. Among them are:

  • Minimized turnaround time. Reporting starts as soon as the machine acquires the order information. The system creates all messages automatically and therefore saves your technologists’ time and increases their productivity.

It helps you to track the exact time needed for the studies and thus to schedule more efficiently. The diagnostic unit immediately informs you about any issues with the studies, which allows you to troubleshoot as quickly as possible.

  • Information accuracy. MPPS eliminates human error. A technologist doesn’t need to report on the examination status since it is done by the equipment. Besides, the machine tells you about the studies which have been actually performed (as we have already mentioned, they may differ from the scheduled examinations).

Together with Modality Worklist, Modality Performed Procedure Step ensures a reliable intercommunication between your information system and diagnostic equipment.

August 15, 2019

EMSOW Weekly Newsletter – August 15, 2019

The survey findings published in Radiology Business say that the vast majority of radiologists see significant value in teleradiology, although there are some disturbing factors, which prevent them from using teleradiology solutions.
EMSOW is a cloud-based end-to-end teleradiology platform to improve your practice and eliminate technical issues. Today, we are proud to present our dispatching service in action (really, less than two minutes).

Automate your technologist management with EMSOW. In the Dispatch module, you can assign exams to imaging technologists in two clicks and track the exams status 24/7.

August 7, 2019

EMSOW Weekly Newsletter – August 7, 2019

Industry news

On August 1, FDA published a list of recommendations to ensure the safety of patients and staff in MRI environments and improve safety testing and MRI information in medical device labeling.

EMSOW Release

[#18922] Dispatch Turnaround Time Analysis module

Now you can easily view, compare, and analyze the turnaround time of your facilities. We have created a new module, where you can filter the list of exams by referring facility and see turnaround time for each exam as well as average time for the selected date range. To access it, go to the Analysis module and select Dispatch Turnaround Time Analysis in the dropdown menu.

Turnaround time module

[#18758] Set the modalities to be displayed in AMI viewer

There are two image viewers available in EMSOW. Some of our customers prefer to view images of particular modalities on EMSOW viewer, instead of AMI viewer. Now you can customize AMI viewer on your EMSOW domain by choosing the modalities to be displayed in it. To apply this option, please contact our support at

July 31, 2019

EMSOW Weekly Newsletter – July 31, 2019

Industry News

Radiologists tend to show the highest interest in telemedicine compared to other physicians, reports Doximity.
This trend can lead to a growing demand for teleradiology platforms. Since 2009 EMSOW has been offering a cutting-edge radiology platform, tailored especially for radiology business at a very reasonable price.

[#16984] Create documents based on templates

Besides file uploading and paperwork scanning, you can now use templates to create documents in EMSOW! Click the “Documents” button and then click “Add using templates” to create a new document:

Add using template

This functionality is available in the Processing and Dispatch modules, as well as the Rendering Provider and Technologist portals. To set up document templates, administrators should go to Setup → Reading → Report Templates.

[#18431] Billing charges for multiple billing companies

Now you can specify more than one billing company in one billing charge record, instead of creating a separate record for each of your billing companies. Go to Setup → Billing → Billing Charges, create or edit a record for a CPT code, and use the “Billing companies” drop-down list:

Multiple billing companies

July 25, 2019


We asked our customers to choose the top 5 features for the last month. Here they come…

#1 Rendering Provider portal

Here, you can create studies in order to save the results of your work with patients. You can also add notes to the studies based on customizable templates. User-friendly search filters allow you to filter the studies by any criteria, from the date of service to the patient’s or doctor’s name.

Rendering Provider Portal

#2 New “Enterprise administrator” user group

We have added a new user group called Enterprise administrator. This group provides extended user rights and can be assigned to advanced EMSOW users who wish to set up and fine-tune EMSOW to meet their own needs and bring the highest level of efficiency to their system.

#3 Technologists can clock in and out via web browser

To enable this functionality, an enterprise administrator should click “Admin” → “Terminals” and create a new terminal record with the “Kiosk technologist time tracking module” option. Then your technologists will be able to go to your domain and check in. After they are done working, the technologists should go to the same address and check out.

Tech Check-in

#4 Copy diagnoses in Service Edit window

Save the time you spend on entering the same diagnoses for several studies. Make a single click, and the system will automatically copy all the diagnoses to the rest of the studies, if their Diagnosis fields are empty.

Dx Copy

#5 Copy address from “Nursing home” type referring facilities

We have increased the automation of data entry. Now you can copy the address of a referring facility to service records if the referring facility is a nursing home.

Address Copy

If you want to learn more about our updates or services, please feel free to contact us at
