June 12, 2019

EMSOW Weekly Newsletter – June 12, 2019

Healthcare IT News

A group of Japanese researchers has made a significant contribution to the use of Computer-Aided Detection (CAD) software. They have revealed and described a way how the CAD software can help quantify pulmonary fibrosis in lung cancer patients. The findings are published in the Radiology journal.

Meanwhile, we have released a useful feature to save your time and improve the efficiency of your team.

[#18760] Copy diagnoses in Service Edit window

If you deal with services consisting of multiple studies, there’s good news. Now you can save the time you spend on entering the same diagnoses for several studies. Click the Copy button to the right of the Diagnosis field, and the system will automatically copy all the diagnoses to the rest of the studies if their Diagnosis fields are empty.


June 5, 2019

EMSOW Weekly Newsletter – June 5, 2019

Healthcare IT News

If you’ve been following industry news, you have probably noticed that AI is becoming extremely popular in medical imaging. Last week Chinese researchers published their findings on improving an AI algorithm, which detects pulmonary nodules.

Another rapidly developing field is healthcare business automation. This week EMSOW developers have created a dedicated portal for nurse practicioners and physician assistants.

[#18663] Rendering Provider portal

To improve EMSOW’s usability for clinical practitioners, we have created the Rendering Provider portal. Here, you can create studies in order to save the results of your work with patients. By clicking the “Edit worksheet” button, you can add notes to the studies based on customizable templates. User-friendly search filters allow you to filter the studies by any criteria, from the date of service to the patient’s or doctor’s name. To get yourself set up with the new module, please contact EMSOW support at support@emsow.com.

[#18017] Referring accounts and insurance groups in reading and billing Rules

Previously, there was no functionality for adding referring accounts and insurance groups to Reading and Billing rules. We have added the corresponding conditions to the Reading Rules and Billing Rules modules, and also added search filters for these conditions.

Moreover, now you can select, add and remove the conditions as easily as never before. Just click the icon to the right of the Conditions section and use the dropdown menu.


May 29, 2019

EMSOW Weekly Newsletter – May 29, 2019

Medical imaging news

IT and Artificial intelligence are strengthening their presence in the imaging industry. Last week researchers at the American College of Radiology reported their findings on improving the AI algorithm of thyroid nodules risk stratification.

This week EMSOW team has been working on optimizing automation and user-friendliness of our system.

[#18639] Automatically send images for reading upon preliminary report completion in Processing

Previously, reading rules were not automatically triggered when you used the Processing module to complete a preliminary report, unlike the PACS Storage and Technologist Portal modules. Now the system automatically sends images for reading upon clicking the “Complete preliminary report” button in any module, given that an applicable reading rule exists.


May 23, 2019

Setting up Your Ultrasound System: Modality Worklist Configuration

The DICOM standard has become a substantial component of today’s imaging technology. It offers such features as Image Storage, Structured Reporting, Modality Performed Procedure Step (MMPS), and Modality Worklist. The vast majority of modern imaging equipment as well as software is DICOM compliant. However, to use advanced DICOM capabilities, an imaging technologist may need specific training, skill and practice, and it does not always come easy. Therefore, a lot of useful tools may remain unused or simply ignored. We would like to share an insight into DICOM benefits.

Previously, we spoke about essential features of DICOM Modality Worklist. Now let us move from theory to practice. We are going to set up MWL on the Mindray M7. This portable ultrasound machine is a popular choice for many sonographers. If you use another model, our quick guide might still be useful, because different systems often follow a similar structure in their settings.

If you have been following our blog, you know that diagnostic equipment sends patient queries to a DICOM Worklist server and thus needs to be connected to it. So, first, we need to add the DICOM server to our machine, if you have not done it yet.

Enter the Setup menu by pressing the Setup button, then go to Network Preset and select the DICOM server you need to add. The Server screen will open.

There are only two parameters you need to enter here: Device, which refers to the name of your equipment unit, and IP address of the Worklist server.

Use the Add and Delete buttons for adding and deleting servers.

You can also check the network connection between your machine and the selected server by clicking the Ping button in the Device area.

The next step is configuring the Modality Worklist. All the preferences are set on the Worklist Page. To enter it, follow the path: SetupNetwork PresetDICOM Service Worklist.

Select the needed service in the Service list and enter its info, then click Add. At this stage, there are a few more parameters you need to enter: Device, Service name (which refers to the Worklist server), AE Title (AE stands for Application Entity; its title is locally unique), Port (DICOM communication port number) and Scheduled Station AE Title.

If you need to change some settings, select a device, enter the new parameters in the Configuration area (right above the Service list), then click Update.

Similarly, you can delete the unnecessary items or set the server as the default one by clicking the corresponding buttons on the Worklist tab.

After that, you need to verify the connection by selecting an item in the service list and clicking the Verify button.

When done, click Exit.

All set. Now you can proceed to sending queries from your machine to the Worklist server.

MWL configuration is not as sophisticated as some technologists might find it. Anyway, if you have any issues concerning the Modality Worklist settings, please refer to the official operator’s manual or contact your vendor.


May 22, 2019

EMSOW Weekly Newsletter – May 22, 2019

Medical imaging news

News from the Society of Magnetic Resonance Radiographers & Technologists (SMRT). MRI has shown that even a small amount of cannabis causes changes in the adolescent brain.

As for EMSOW, our recent update is aimed at improving your reports so that you could present your findings in the best possible way.

[#18635] Additional signature in report addendums

From now on, amended reports from reading doctors will include an “Amended by” line specifying the name of the doctor who amended the report.
